iCam-D25

5MP AI IR Mini Dome Network Camera

Product Overview

iCam-D25 is an indoor super mini camera with 5MP QHD resolution and stylish design. The perfect combination of Intelligent Infrared and day/night function greatly improve the visibility effect in the dark and low-light environments. The iCam-D2 series supports standard H.264/H.265 and also the stanard onvif protocol. The optional Wi-Fi model(-W) offers wireless communication and easily setup. The edge storage SD card slot can support up to 128GB micro SD card. The device has built-in person detection and vehicle detection functions and you can easily get event alarm from the IntelliSight mobile APP.The Built-in Microphone and Speaker interface support audio events and two-way audio.

Product Features

  • High Definition up
    to 5M
  • True Day/
    Night
  • Built-in
    Microphone
  • Smart Events
  • Edge Deep
    Learning Engine

Product Scenes

Business Meeting Room
Lobby and Receptions

Product Specifications

Model
iCam-D25
iCam-D25W
Camera
Image Sensor 1/2.7" 5 Megapixel Progressive Scan CMOS
Max. Resolution 2880(H)x1620(V)
Shutter Time 1/12s ~ 1/10000s
Minimum Illumination Color: 0.01Lux @(F1.2,AGC ON)
B/W: 0Lux @(IR LED ON)
Day/Night IR-CUT with Auto Switch/Scheduled
WDR HDR
BLC Support
Lens
Mount Type Fixed M12
Focal Length 2.8mm (0.11")
Aperture F1.8
FOV 105°(H)
Iris Type Fixed
Illuminator
IR Range Up to 10m (393.70")
Wavelength 850nm
Audio
Audio Compression G.711, G.72 6, AAC-LC
Audio Type Mono
Audio Capability Environmental Noise Filter, Echo Cancellation, Two-way Audio
Video
Video Compression H.264, H.265
Video Bit Rate 512kbps ~ 16mbps
Resolution Main Stream (2880*1620, 2560*1440, 1920*1080, 1280*720)
Sub Stream (1920*1080, 1280*720, 704*576, 640*480)
Third Stream (1280*720, 704*576, 640*480)
Region of Interest (ROI) 4 Fixed Regions for Each Stream; Target Cropping of Third Stream
Image Setting Saturation, Brightness, Contrast, Sharpness, Auto white balance
Image Enhancement Lens Distortion Correction, Defog, 2D/3D DNR
S/N Ratio 39dB
Dynamic Range >100dB
Others OSD, Image Flip, Picture Overlay
Smart Events
Video Analytics Defocus Detection, Scene Change Detection, Occlusion Detection
Smart Events Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Loitering Detection
Deep Learning Events Vehicle Detection, Face&Pedestrian Detection, Face Match (-P), ANPR (-C)
Network
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, IPv4, IPv6
Compatibility ONVIF, GB28181, CGI API
Management IntelliSight Cloud Desktop Software, IntelliSight Mobile APP
Interface
Ethernet 1 RJ45 (10/100Mbps)
WIFI / IEEE 802.11 b/g/n
Storage Built-in MicroSD/SDHC/SDXC Slot, up to 128 GB
Audio 1 Built-in Mic, 1 Built-in Speaker
Key Reset Button
General
Power Supply DC12V 1A/POE (IEEE 802.3af)
Power Consumption <6W
Operating Conditions -10°C to 50°C (14°F to 122°F), Humidity: 10% to 90% (No Condensation)
Certifications CE, FCC, RoHS
Weight 1.5KGS
Dimensions Φ100.4*50.7mm (Φ3.95*2.00")
