CrossChex Cloud

C2 Series

Outdoor Compact Access Control and Versatile Time & Attendance Devices


C2 Series (C2 Pro, C2 Slim, C2 KA and C2 SR) is a biometric identification and RFID card access control & time attendance based on Anviz's advanced technology. With the mullion-mount, keypad design, and IP65 dust & waterproof, the C2 Series can be installed in various environments and outdoor installation, turnstiles etc. It provides installers with lower installation and maintenance costs by supporting PoE. C2 Series also supports dual-frequency (125kHz/13.56MHz) cards with the multi-smartcard reader, HID iClass & Prox cards and communications with smartphones to access the door. C2 Pro with fingerprint scanner, RFID reader and personal PIN offer versatile punching options, plus CrossChex Cloud time attendance software support, super easy time tracking which provides hassle-free workforce management.

Where to Buy

We'll connect you with a partner in your area

PS3Perú

  • img country

    Perú

  • img website s3peru.com
  • ventas@s3peru.com

  • img tel

    (051) 01 637-2786 - (051) 01 637-2787

Map Teknoloji

ISS

  • img country

    Guatemala

  • img website issgt.com
  • ricky@issgt.com

  • img tel

    +502 5185-7871

SolvIT sh.p.k

Euroma

  • img country

    Spain

  • img website euroma.es
  • info@galaxysecurity.com

  • img tel

    +34 915 711 304

Watstelecom S.A.R.L

Sistemas Integrales De Automatizacion, S.A. De C.V.

  • img country

    Mexico

  • img website siasa.com
  • clizama@siasa.com

  • img tel

    (999) 930 2575

JM SS SRL

  • img country

    Dominican Republic

  • img website
  • agonzalez@jmsecuritysystem.com

  • img tel

    809-475-2210



Biometric Access Control & Time Clock System
  • Biometric Access Control & Time Clock System
    IP65 Dust & Water Proof
  • Biometric Access Control & Time Clock System
    Multi-Smartcard Reader
  • Biometric Access Control & Time Clock System
    Mobile Access
  • Biometric Access Control & Time Clock System
    PoE Easy Installation
  • Biometric Access Control & Time Clock System
    Mullion-type Design
Biometric Access Control & Time Clock System

Increased 30% Recognition Speed Compare to the Last Version

  • 30% Performance
    increased
  • Max.10,000 Users
  • Max.100,000 Logs
Biometric Access Control & Time Clock System

Multi-Smartcard Reader

Support 125kHz and 13.56MHz RFID including MIFARE, MIFARE Plus, DESFire, MIFARE Ultralight, FeliCa and EM, HID iClass & Prox. NFC will be introduced in the future.

Biometric Access Control & Time Clock System

Communicates with Smartphones

With Anviz CrossChex Mobile App, your smartphone is a key to access.

  • Biometric Access Control
  • Time Clock System

Mullion-type Design

Mount easily with a small access control terminal that can easily be installed on a door frame.

Biometric Access Control Time Clock System
Time Clock System

IP65 Dust & Water Proof

C2 Series access control terminals are designed to be used indoor and outdoor applications coupled with IP65 ingress protection.

  • Biometric Access Control
PoE Easy Installation

PoE Easy Installation

Support power sourcing over Ethernet cable compliance to IEEE802.3af standard, to provide users with lower installation cost, simpler cabling, and lower maintenance cost.

Applications

People are passing the turnstiles with Anviz biometric access control terminals

C2 Series can be used as a turnstile integrated management system composed of computers, fingerprint identification technology, intelligent pedestrian turnstile gate, smart card, access control, and time attendance management software.

Further, C2 Series has been regarded as a top physical and logical access control system to solve the security concern of enterprises.

tracking software could generate timesheets

Using CrossChex Cloud as a time attendance software to automatically generate a timesheet to track the time a particular employee has worked during a certain period.

Due to fingerprint scanner like C2 Pro supports the both biometric identification and biometric authentication, it is an established solution that is being used in time attendance management.

Open the door with your phone

When it comes to choosing a reliable commercial door entry with smartphone mobile, C2 Series is always a better investment.

RFID door lock system combined with biometric readers of C2 Series enhanced door security, especially for high-security applications such as in medical, financial, or government facilities.

Configuration

Time Clock System

Specification

Model Name C2 SR C2 KA C2 Slim C2 Pro
  Access Control Time Clock System Access Control Time Clock Biometric Access Control System Biometric Access Control
General Identification Mode Card Card, Password Finger, Card Finger, Password, Card
RFID Options 125kHz EM & 13.56MHz MIFARE 125kHz EM & 13.56MHz MIFARE 125kHz EM & 13.56MHz MIFARE,
HID iClass & Prox (HID Version)
125kHz EM & 13.56MHz MIFARE,
HID iClass & Prox (HID Version)
Capacity Max. Users 10,000 3,000 10,000
Max. Cards 10,000 3,000 10,000
Max. Logs 100,000 50,000 100,000
Function Time Attendance Mode 8
Group, Time Zone 16 groups, 32 time zones 16 groups, 32 time zones 16 groups, 32 time zones
Work Code 6 digits
Short Message 50
Web Sever
Record Auto Inquiry
Daylight Saving
Voice Prompt Voice Voice Voice
Multiple Language
Software CrossChex Standard CrossChex Standard CrossChex Standard & CrossChex Cloud
Mobile
Hardware CPU 32-bit Processor 1.0 GHz Processor 1.0 GHz Processor Dual-core 1.0 GHz Processor
Fingerprint Sensor AFOS Touch Active Sensor AFOS Touch Active Sensor
Finger Scanning Area 22mmx18mm (0.87x0.71") 22mmx18mm (0.87x0.71")
Display 3.5" TFT
Keypad Physical Button Physical Button
Dimensions(W x H x D) 50x159x25mm (1.97x6.26x0.98" 50x159x25mm (1.97x6.26x0.98") 50x159x32mm (1.97x6.26x1.26") 140x190x32mm (5.51x7.48x1.26")
Working Temperature -10°C~60°C (14°F~140°F) -10°C~60°C (14°F~140°F) -10°C~60°C (14°F~140°F) -10°C~60°C (14°F~140°F)
Humidity 20% to 90% 20% to 90% 20% to 90% 0% to 90%
PoE IEEE802.3af IEEE802.3af IEEE802.3af
Power Input DC12V DC12V DC12V DC12V
IP Grade IP65 IP65 IP65
I/O TCP/IP
RS485
USB Host
Wi-Fi
Bluetooth
Relay
I/O Door Contact/ Exit Button Door Contact/ Exit Button Exit Button
Tamper Alarm
Wiegand Output Input & Output Input & Output Output
