Touchless and Infrared Thermal Temperature Screening Face Recognition Terminal

FACEPASS 7

Simply Look and Go

FacePass 7 is equipped with a new Linux CPU, implementing a face-capturing of less than 1 second, and a recognition time within 0.5 seconds.

Identification time

Registration time

Facial Algorithm


	Ear Thermometer	Forehead Thermometer	IR Thermal Detector
Touchless	Touch	Touchless	Touchless
Technology	Single Point Detection	Single Point Detection	32*32 pixels surface detection
Detection Distance	0	1-3 cm	Maximum 50 cm
Detection Way	Manually	Manually	Automatic Detection
Detetion Speed	12 People/ Minute	12 People/ Minute	500 People/ Minute *Only for temperature detection
Deviation	± 1 °C	± 1 °C	± 0.3 °C
Applications	Home/ Small Public Places Office/ Clinic/ Retail Store	Home/ Small Public Places Office/ Clinic/ Retail Store	Medium to Large Public Places (Hospital/ Shopping Malls/ Enterprises)

Flexible communication for WiFi, 4G or Lan. Convenient management for Web-server and PC software.

Model		FacePass 7 IRT
Capacity	User Capacity	3.000
	Card Capacity	3.000
	Log Capacity	100.000
Interface	Communication	TCP/IP, RS485, USB Host, WiFi, Optional 4G
	I/O	Relay Output, Wiegand Output, Door Sensor, Switch, Doorbell
Feature	Identification	Face, Card, ID+Password
	Verify Speed	<1s
	Image Display	Support
	Self-defined Status	10
	Record Self-check	Support
	Embedded Webserver	Support
	Doorbell	Support
	Multi-languages Support	Support
	Software	Crosschex Standard
Hardware	CPU	Dual-core 1.0GHz
	Infrared Thermal Temperature Detection Module	10-50°C Detection Range Detect Distance 0.3-0.5 m (11.8 -19.7 inch) Accuracy ±0.3 °C (0.54 °F)
	Face Detection Camera	Dual Camera
	LCD	3.2" HD TFT Touch Screen
	Sound	Support
	Angle Range	Horizontal: ±20°, Vertical: ±20°
	Verify Distance	0.3-0.8 m (11.8-31.5 inch)
	RFID Card	Standard EM, Optional Mifare
	Tamper Alarm	Support
	Operating Temperature	-20 °C (-4 °F)- 60 °C (140 °F)
	Dimensions{W x H x D)	12415592 mm (4.96.13.6 inch)
	Operating Voltage	DC 12V
